1. Processor (CPU

Number of slots: 2

Supported processor: 2nd Generation Intel® Xeon® Scalable Processor (Cascade Lake)

Maximum number of cores: A single CPU has a maximum of 28 cores (such as Xeon Platinum 8280)

Accelerated instruction set: Supports AVX-512, optimizing high-performance computing

2. Memory (RAM)

Number of slots: 24 DDR4 DIMMs (6 channels)

Maximum capacity: 3TB (Single 128GB LRDIMM)

Frequency support: 2933MHz

3. Storage configuration

Front drive

12 hot-swappable 3.5-inch or 24 2.5-inch hard disks

Supports SAS/SATA/NVMe hybrid configuration

RAID support:

Huawei ES3000 RAID card (supports RAID 0/1/5/6/10/50/60)

4. Expansion capability

PCIe slot

7 PCIe 3.0 slots (supporting full height/half height)

Compatible with GPU accelerator cards such as NVIDIA T4/V100

Network interface

It is equipped with 4 10/25GbE (Huawei self-developed network cards) on board.

Optional 100Gb InfiniBand

5. Power Supply and Heat Dissipation

Power module

800W/1200W platinum-level redundant power supply

Heat dissipation system

Intelligent zonal speed-regulating fan

6. Management and Safety

Remote management

Huawei iBMC intelligent management system

Safety function:

TPM 2.0 Encryption Module

7. Physical Specifications

Dimensions: 2U rack-mounted (87.5mm high × 447mm wide × 800mm deep)

Weight: ≤ 30kg (Full configuration)

8. Software support

Operating system

Huawei EulerOS, CentOS, Windows Server

Virtualization platforms (VMware ESXi, Huawei FusionSphere)

9. Typical application scenarios

Cloud computing virtualization

Enterprise core database

AI reasoning and Training

Core advantage

✔ High-density computing: 2U space supports 24 hard disks

✔ Flexible expansion: 7 PCIe slots

✔ Smart Management: iBMC Remote operation and maintenance
