FEATURES

Battery Input Voltage Range: 1.8V to 5.5V

100nA Quiescent Current

8 Primary Battery Peak Input Current Limits: 5mA/10mA/15mA/20mA/25mA/50mA/75mA/100mA

SOH Monitor for Primary Battery

Integrated Coulomb Counter (Q)

Additional Monitors for Battery Voltage (V), Battery Impedance (Z), and Temperature (T)

Primary Battery Current (BAT_IN) or Load Current (BAT_OUT) is Counted

Integrated ±10mA Supercapacitor Balancer

Programmable Coulomb Counter Prescaler for Wide Range of Battery Sizes

Programmable Discharge Alarm Threshold with Interrupt Output

I²C Interface

Tiny 12-Lead 2mm × 2mm LFCSP and 16-Ball 1.64mm × 1.64mm WLCSP Packages

APPLICATIONS

Low Power Primary Battery Powered Systems (e.g., 1× LiSOCl2, 2–3× Alkaline)

Remote Industrial Sensors (e.g., Meters, Alarms)

Asset Trackers

Electronic Door Locks

Keep-Alive Supplies/Battery Backup

SmartMesh® Applications
